HMC1057-SX

Part number:

HMC1057-SX

Manufacturer::

Analog Devices Inc.

Factory Pack Quantity:

Inquiry

Write a Review

Product Specifications

Product Attribute	Attribute Value
Manufacturer:	Analog Devices Inc.
Product Category:	RF Mixer
RoHS:	Details
RF Frequency:	71 GHz to 86 GHz
Conversion Loss - Max:	15 dB
NF - Noise Figure:	-
LO Frequency:	29 GHz to 43 GHz
IF Frequency:	DC to 12 GHz
Maximum Operating Temperature:	+ 85 C
Minimum Operating Temperature:	- 55 C
Mounting Style:	SMD/SMT
Package / Case:	Die
Brand:	Analog Devices
Packaging:	Gel Pack
Product Type:	RF Mixer
Series:	HMC1057G
	2
Subcategory:	Wireless & RF Integrated Circuits
Technology:	Si
Unit Weight:	0.412264 oz

FAQ

What is a "short circuit"?

A "short circuit" is an unwanted connection of very low resistance such as a wire (almost 0) which provides a very easy path for current. Think of it as an electrical short-cut. It is normally used to describe a fault or accidental connection rather than a deliberate one.
For example: if the leads from a battery touch one another they create a very low resistance connection across the battery, so we say they have caused a short circuit across the battery. Current will flow through this short circuit rather than through the proper circuit. This stops the circuit working and it may cause a fire because the leads and battery will become hot with a large current flowing.

What is a schematic?

It is another name for a circuit diagram.

What does "open circuit" mean?

"Open circuit" means no connection. It is usually used to describe a break in some part of a circuit which could be deliberate (such as a switch in the open or off position) or a fault (such as a broken wire or burnt out component).
